- Description
Description
AV3601
Aspes Vitroceramic Hob 6200W 5.1cm 59cm 52cm Black Glass Touch 3Z Triple Crown
Description
Aspes 60cm wide glass ceramic hob model AV3601.
3-zone hob with a total power of 6200 W. One of the zones is a triple crown, so it can be adapted to larger diameter containers.
Aesthetic black glass and touch control system with 9 cooking power levels and functions to obtain the highest performance and safety in the cooking process.
Dimensions: 51 x 590 x 520 mm
Required dimensions for the embedding: 560 x 480 mm
Learn more about this model:
– The hob offers the Auto-off function to ensure greater safety. When it detects that no changes are made to an activated zone for a long time, it will automatically switch off.
– Also noteworthy are the panel locking functions, timer of up to 99 minutes and residual heat indicator in the zones.
TECHNICAL SPECIFICATIONS
Hob colour: Glass, black
Bevelled edges: Yes
Cooking levels: 9
Control system: Touch
Installation type: Built-in
Triple crown: Yes
Cooking zones: 3
Hob type: Vitroceramic
FUNCTIONS
Safety auto-off: Yes
Control lock: Yes
Residual heat indicator: Yes
Home automation system: No
Timer: Yes
Timer (time/duration): 99min
PERFORMANCE
Frequency: 60Hz
Zone 1 power: 1200W
Total hob power: 6200W
Zone 2 power: 1800W
Zone 3 power (min.): 1050W
Zone 3 power: 2700W
Voltage (max.): 240V
DIMENSIONS AND WEIGHTS
Packaging height: 115mm
Packaging width: 690mm
Packaging depth: 645mm
Product height: 51mm
Product width: 590mm
Product depth: 520mm
Built-in width: 560mm
Built-in depth: 480mm
Zone 1 diameter: 165mm
Zone 2 diameter: 200mm
Zone 3 diameter: 300mm
Zone 3 diameter (small): 155mm
Zone 3 diameter (medium): 230mm
Gross weight: 9kg
Net weight: 5kg, 7
Volume: 0, 05118m3
